Description
Specifications
Cable Specifications:
Operating temp: -45°C (-49°F) to +70°C (+158°F).
Capsule Enclosure: Injection molded high resistant plastic
Size of capsule: 69mm x 42mm x 30mm (2.7” x 1.65” x 1.18”)
Weight: 50 gr.
Comm Cable: Shielded AWG gauge six wires cable.
Life expectancy: 15 years field operation
SPU Specifications:
Includes:
SPU-2004 Transponder card
LP-05 Lightning protection card
E-Clips 6
E-Clips 10
Input voltage: 8.5 – 32 VDC
Current consumption: 10 – 35mA at 15 VDC
Transponder card internal voltage: 5 VDC
“No Alarm” input voltage: 2.5 VDC
Open circuit “Alarm” input voltage: 4.5-5 VDC
Short circuit “Alarm” input voltage: 0 – 1.5 VDC
Communications: RS-485 channel.
Processing: Alarm: Yes/No decision.
8 zone signal processing.
Size: 100 x 250 x 190 mm (4″ x 10″ x 7.5″)
Weight: 1 Kg. (2 Lbs.)
